DEGONG
• It is equipped with Luoyang YTO engine which features environment-friendly performance, strong power, high efficiency, energy saving, low noise and low emission.
• The advanced Z-type reverse tipping bucket mechanism contributes to large breakout force and high work efficiency.
• The automatic bucket leveling function reduces the driver’s work intensity.
• The travel system adopts power shift transmission and articulated full hydraulic steering mechanism.
• The transmission and torque converter adopt separated structure, which is very convenient for maintenance.
• There are also variant products like mining loader, anti-explosion loader, side dump loader, grass grasper, etc.
|
Parameters |
Value |
Parameters |
Value |
||
|
Bucket capacity |
1.0m3 |
Fuel tank volume |
105L |
||
|
Max. travel speed |
27km/h |
Max. traction force |
54KN |
||
|
Rated load |
2t |
Automatic bucket leveling |
Available |
||
|
Operating weight |
6.2t |
Service brake/parking brake |
Caliper disc/hand brake |
||
|
Engine |
Model |
LR4B3-24 |
Work cycle time |
8s |
|
|
Rated power |
60kW |
Dump height |
Standard |
2460mm |
|
|
Rated revs |
2400rpm |
Long reach |
2850mm |
||
|
Min. fuel consumption |
242g/kwh |
|
|
||
|
Max. torque |
280N.M |
Dump distance |
Standard |
800mm |
|
|
Dimension (L×W×H) |
5930×2078×2850mm |
Long reach |
865mm |
||
