Model Item

TS75

Rated power (kw)

55

Max. Speed ( km/h )

12

Track Model

320X84X54

Operating load (kg)

1000

Bucket capacity (m3)

0.5

Hydraulic Flow (L/min)

80/120

Fuel tank capacity (L)

90

Weight (kg)

3800

Model Item

TS75

A

Overall operating height (mm)

3480

B

Height to bucket hinge pin (mm)

2900

C

height to top of cab (mm)

2150

D

Height to bottom of bucket(mm)

2730

E

Overall length without bucket ( mm )

2750

F

Overall length with bucket(mm)

3500

G

Dump angle at maximum height(° )

40

H

Dump height(mm)

2230

I

Dump reach(mm)

715

J

Rollback at ground position(° )

30

K

Rollback fully raised at max height (°)

104

L

Wheelbase(mm)

1500

M

Ground clearance(mm)

200

N

Angle of departure(° )

20

O

Front turning radius without bucket(mm)

1298

P

Front tuning radius(mm)

2010

Q

Rear tuning radius(mm)

1714

R

Tail length (mm)

890

S

Track(mm)

1462

T

Width over track (mm)

1782

U

Bucket width (mm)

1830
