DEGONG
Low fuel consumption, big torque, low noise, superior performance, convenient and flexible operation, higher stability, high efficiency, and more safe and reliable.
• Xichai and Cummins Engine are optional, featuring low fuel consumption, big torque, low noise and
superior performance.
• Power shift
transmission, full hydraulic steering, convenient and flexible operation, and
higher stability.
• The optimal design of Z-type reverse bucket tipping
mechanism contributes to large breakout force and high work efficiency.
• Structural parts made of high quality manganese steel
and reinforced boom contributes to more reliable quality.
• The automatic bucket leveling function reduces the
driver’s work intensity.
• With optimally designed drive system and hydraulic
system, it has higher travel speed and work efficiency.
• Heavy weight and long axle base make it more stable
during operation.
• Equipped with articulated frame, it has small turning
radius.
• It adopts air over hydraulic caliper disc single
pipeline brake system, with high quality polyurethane high pressure hose, which
is more safe and reliable.
• The pin shafts for the working device are all mounted
with anti-dust device, which prolongs the service life.
• The ergonomically designed cab has wide view and
comfortable vibration absorption seat, which is more safe and reliable.
• With multiple working devices like log grasper, grass
grasper, coal bucket, rock bucket, high dump device, breaker, etc. the machine
can handle various kinds of work.
Parameters
|
Major Specification |
938N |
||
|
engine model |
WP6G125E201 (WEICHAI) |
6BT5.9-C125-II (CUMMINS) |
|
|
rated Power（Kw) |
92 |
92 |
|
|
rated speed(r/min) |
2000 |
2000 |
|
|
articulated steering angle(° ) |
36 |
36 |
|
|
minum turning radius(mm) |
5320 |
5320 |
|
|
maximum breakout force (Kn) |
105 |
105 |
|
|
maximum traction force (Kn) |
110 |
110 |
|
|
wheel base (mm) |
2700 |
2700 |
|
|
wheel track(mm) |
1856 |
1856 |
|
|
maximum climbing capacity(° ) |
30 |
30 |
|
|
dimension (L*W*H) |
7170*2484*3235 |
7170*2484*3235 |
|
|
discharge height |
3057 |
3057 |
|
|
discharge distance |
906 |
906 |
|
|
operating speed(km/h) |
forward 4 backward 2 |
|
|
|
forward |
1st |
7 |
7 |
|
2nd |
12 |
12 |
|
|
3rd |
23 |
23 |
|
|
4th |
37 |
37 |
|
|
backard |
1st |
9 |
9 |
|
2nd |
28 |
28 |
|
|
fuel capacity(L) |
150 |
150 |
|
|
hydraulic time(s) |
9 |
9.2 |
|
|
max travel speed (km/h) |
37 |
37 |
|
