★Weichai DEUTZ WP6G125E23 diesel engine, higher power and reliability;
★Hangzhou Advance Gear Group double-turbine hydraulic torque converter with reasonable structures and higher reliability make the loader obtaining more drawing force;
★Gear-shift with 2 forward and 1 reverse controlled by flexible shaft eases much labor;
★Single lever pilot control system, comfortable and flexible operation;
★Single pump, split flow working hydraulic system realizes the excellent fuel economy;
★Double sealed hydraulic pipeline joints with 24° awl and 〇 ring of international standard, avoided oil leak- age obviously;
★Fully hydraulic load sensing steering system, flexible operation and higher reliability;
★Air over hydraulic disks on four wheel brakes;
★Large space articulated frames make operation and traveling stable;
★Working device with automatically leveling ability at high position;
★Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability;
★Integral, luxury instrument board;
★New, luxury cabin.
Item |
Specifications |
Item |
Specifications |
Bucket capacity |
1.8 m3 |
Rated power |
92kW/2200rpm |
Rated load |
3000kg |
Tyre |
17.5-25 |
Dumping height |
3000mm |
Overall dimensions |
6910 x2510 x3230mm |
Max. breakout force |
120kN |
Operating weight |
10200kg |
Max. drawing force |
96kN |
|
|
Optional: Dongfeng Cummins 6BT5.9-C130 engine; ROPS/FOPS cabin; Quick hitch & attachments.
