★Adopt
Xinchai A4K41G diesel engine;
★Hydrodynamic transmission technology and separated structure,make high reliability and easy maintenance;
★Controlled by flexible shaft, hydraulic power shift gearbox
with 2 forward and 2 reverse gears makes operate easy;
★Single pump, split flow working hydraulic system makes lower
consumption and excellent performance;
★Double sealed hydraulic pipeline joints with 24° awl and 〇 ring of international standard,avoids oil leakage obviously;
★Load sensing fully hydraulic steering system makes operation
easy;
★Air over hydraulic brake system; Caliper disc brakes;
★Working device with automatically leveling ability at high
position;
★Bucket articulated points take sealed, lubricated, dust-proof
layers, which owns good durability;
★Integral, luxury instrument board;
★New, luxury cabin.
Item |
Specifications |
Item |
Specifications |
Bucket capacity |
0.9 m3 |
Max. grade ability |
28° |
Rated load |
1800kg |
Rated power |
50kW/2400rpm |
Dumping height |
2750mm |
Tyre |
16/70-20 |
Max. breakout force |
46kN |
Overall dimensions |
5520 X1950 X 2670mm |
Max. drawing force |
35kN |
Operating weight |
5300kg |
Optional: Lovol 1004C diesel engine; Dongfeng Cummins 4BTA3.9-C100 diesel engine; Joystick control; Quick hitch.
