KAILONG
★Adopt Xinchai A495BG Diesel Engine;
★Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operate easy;
★Single pump, split flow working hydraulic system makes lower consumption and excellent performance;
★Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
★Load sensing fully hydraulic steering system, easy and flexible operation;
★Air over hydraulic brake system; Caliper disc brakes;
★Working device with automatically leveling ability at high position;
★Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability;
★Integral, luxury instrument board;
★New, luxury cabin.
|
Item |
Specifications |
Item |
Specifications |
|
Bucket capacity |
0.5 m3 |
Max. grade ability |
35° |
|
Rated load |
1000 kg |
Rated power |
36.8kW/2400rpm |
|
Dumping height |
2660 mm |
Tyre |
12-16.5 |
|
Max. breakout force |
34 KN |
Overall dimensions |
5290×1680×2680mm |
|
Max. drawing force |
30 KN |
Operating weight |
3700kg |
Optional: 1.Joystick control 2.Quick-hitch 3.Forklift 4.ROPS
